3PCS Joystick Sensor Dual Axis Game Controller Dual-Axis XY Control Stick Sensor Breakout Board Module

KWD 3
Brand
VKLSVAN
Weight
35 g
All electronics ship with US style plugs. You may need a voltage converter or a plug adapter.
– 1 +

Special Features

  • Input voltage range: DC 3.3V - 5V; DO port for digital output, AO port for analog output; Bi-directional 10 k resistor, the resistance changes with the rocker in a different direction.
  • In order to allow you to more easily with expansion board and other standard interface, the design of the X, Y, Z axis of the circuit leads alone, the user can use 3-pin special line really plugged into the expansion board for Use.
  • Output signal: module ad hoc two-way analog output and one digital output interface, the output value corresponding to (X, Y) biaxial offset, the type is analog; the button indicates whether the user presses the Z axis, Its type is digital switch.
  • Cross rocker is a bi-directional 10K resistor, with the rocker in different directions, the tap resistance changes. The module uses 5V power supply, the original state of X, Y read-out voltage of 2.5V or so, with the direction of the arrow down, read the voltage value increases with up to 5V; the arrow is pressed in the opposite direction, read the voltage value decreases , The minimum is 0V.
  • Dual-Axis Button Joystick Module：Rocker is generally used in aerial models of drones, video games, RC cars, gimbals and other devices. Many devices with screens also often use rockers as input control for menu selection.

Description

Feature:
1. Input voltage range: DC 3.3V~5V
2. Through the controller programming, plug the sensor expansion board to complete the creative remote interactive works.
3. Output signal: module ad hoc two-way analog output and one digital output interface, the output value corresponding to (X, Y) biaxial offset, the type is analog; the button indicates whether the user presses the Z axis, Its type is digital switch.
4. Cross rocker is a bi-directional 10K resistor, with the rocker in different directions, the tap resistance changes. The module uses 5V power supply, the original state of X, Y read-out voltage of 2.5V or so, with the direction of the arrow down, read the voltage value increases with up to 5V; the arrow is pressed in the opposite direction, read the voltage value decreases , The minimum is 0 V.

Parameters:
Product Name: Rocker module (two-axis button rocker)
Product Size: 34.0mm x 26.0mm x 32.0mm
Material: FR4+ Electronic component

Connection for Arduino and Joystick module:
GND to GND
+5V to 5V
Analoog 0 to VRx
Analoog 1 to VRy
Analoog 2 to SW

Package contain:
3 PCS Game Controller JoyStick Module
