Camera
Image Sensor:1/2.9" Progressive Scan CMOS
Max. Resolution:2688 × 1520
Min. Illumination:Color: 0.005 Lux @ (F1.6, AGC ON),0 Lux with light Shutter Time:1/3 s to 1/100,000 s
Day & Night:IR cut filter
Angle Adjustment:Pan: 0° to 360°,tilt: 0° to 75°,rotate: 0° to 360°
Lens
Lens Type:Fixed focal lens, 2.8mm
Focal Length & FOV:2.8 mm, horizontal FOV 101°, vertical FOV 57°, diagonal FOV 118°
Lens Mount:M12
Iris Type:Fixed
Aperture:F1.6
Depth Of Field:2.8 mm: 1.3 m to ∞
DORI:2.8 mm, D: 61 m, O: 24 m, R: 12 m, I: 6 m
Illuminator
Supplement Light Type:IR,White Light
Supplement Light Range:Up to 30 m
Smart Supplement Light:Yes
IR Wavelength:850 nm
Video
Main Stream:50 Hz:25 fps (2688 × 1520, 1920 × 1080, 1280 × 720);60 Hz:30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream:50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360);60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Third Stream:50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360);60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
Video Compression:Main stream: H.265/H.264/H.264+/H.265+,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
*Third stream is supported under certain settings.
Video Bit Rate:32 Kbps to 8 Mbps
H.264 Type:Baseline Profile,Main Profile,High Profile
H.265 Type:Main Profile
Scalable Video Coding (SVC):H.264 and H.265 encoding
Bit Rate Control:CBR,VBR
Region Of Interest (ROI):1 fixed region for main stream and sub-stream
Target Cropping:Yes
Audio
Audio Compression:G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate:64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Audio Sampling Rate:8 kHz/16 kHz/32 kHz/48 kHz
Environment Noise Filtering:Yes
Network
Protocols:TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
Simultaneous Live View:Up to 6 channels
API:ON-VIF (Profile S, Profile G),ISAPI,SDK,ISUP
Security:Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open Network Video Interface
User/Host:Up to 32 users;3 user levels: administrator, operator, and user
Client:iVMS-4200,Hik-Connect,Hik-Central
Network Storage:NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
Web Browser:Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+,Local service: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+
Image Parameters Switch:Yes
Day/Night Switch:Day,Night,Auto,Schedule
Wide Dynamic Range (WDR):120 dB
SNR:≥ 52 dB
Image Enhancement:BLC,HLC,3D DNR
Privacy Mask:8 programmable polygon privacy masks
Interface
Ethernet Interface:1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage:Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Reset Key:Yes
Built-In Speaker:1 built-in speaker,Max. power consumption: 2 W, max. sound pressure level: 10 cm: 110 dB
Audio:Built-in Microphone: Arrayed dual-microphone
Event
Basic Event:Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage:Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture,audible warning,strobe light flashing
Deep Learning Function:Perimeter Protection;Line crossing, intrusion;Support alarm triggering by specified target types (human and vehicle)
General
Power:12 VDC ± 25%, 1 A, max. 12 W,Ø5.5 mm coaxial power plug,reverse polarity protection
PoE: IEEE 802.3at, Class 4, max. 16 W
Material:Metal
Dimension5" × 3.8"
Weight:1.1 lb
Storage Conditions:-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup And Operating Conditions:-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language:33 languages
General Function:Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
Flashing Light:SRB models: Red and Blue Light;Other models: White Light
